Marine clear paint protection film surface detail

NEO-Marine PPF

Gloss-MG85
Log in to view prices
Skip to product information
Marine clear paint protection film surface detail
  • Marine clear paint protection film surface detail
  • Standard Gloss clear paint protection film roll
  • Premium Matte clear paint protection film installed on vehicle
  • Premium Matte clear paint protection film roll
  • Premium Matte clear paint protection film surface detail
NEO-Marine PPF

NEO-Marine PPF

Log in to view prices
Finishing

FAST GLOBAL
SHIPPING

3-4 business day expedited delivery across America, 5-6 days worldwide

RELIABLE
QUALITY

Up to 6-years warranty for PPF with hassle-free on-line claim process

AVAILABLE
IN STOCK

95% of 400+ PPF colors are always in stock — no backorders, no delays

STRICT
CONSISTENCY

Batch variation strictly controlled within 5% for consistent PPF color matching

NEO-Marine PPF

NEO-Marine PPF is the current NEOPPF marine-film listing. Review the page-specific performance table and warranty statement below, then confirm the exact model, intended surface, installation scope and applicable documents before ordering.

Use the model name on this page when requesting the current product data sheet or discussing the project with NEOPPF.

Performance Specs

Product thickness (Total)

280 ± 10 µm

Application layer thickness

210 ± 5 µm, 8.5mil

Peel Adhesion (Tack)

≈ 1500 g/inch

Tensile Strength

21 Mpa

Maximum Temperature

100 ℃

Elongation at Break (Coat)

≈ 150 ℃

Elongation at Break (Product)

≥ 380%

UV Resistance

≥ 95%

Light Transmission

90%+

Film Size Per Roll

1.52m x 15m (60"x50')

Coating type

Hydrophobic Effect



Hydrophobic Coating

NEOPPF features an advanced hydrophobic topcoat, with a water contact angle exceeding 105°, the film resists buildup from mud, bird droppings, tree sap, and other pollutants, helping preserve the vehicle’s appearance with minimal effort.

  • High water repellency for faster drying and easier cleaning
  • Reduced contamination adhesion for a longer-lasting shine
  • Less frequent washing, saving time and maintenance costs

Optical Clarity Technology – CrystalHold™

CrystalHold™ is NEOPPF’s proprietary material enhancement designed to significantly increase the light transmission of TPU films while minimizing yellowing over time. This advanced technology improves long-term visual clarity and preserves the premium appearance of transparent film applications.

CrystalHold™ represents NEOPPF’s commitment to pioneering innovation and quality in performance film technology.

Key Benefits:

·         Enhanced optical clarity to the OEM paint

·         Improved UV stability and anti-yellowing properties

·         Ideal for high-end automotive protection films

Warranty Statement

Coverage: NEOPPF guarantees its Diamond Series to be free from material defects for a period of eight (8) years from the date of production.

Conditions: If a product defect is reported within the warranty period, NEOPPF will evaluate the claim and determine, at its sole discretion, whether to:

·         Replace the defective product at no cost, or

·         Provide a monetary compensation deemed reasonable by NEOPPF.

Testing Standards:

·         QUV testing with UVA bulb exposure at 50°C

·         4-hour condensation cycles at 60°C

Before ordering NEO-Marine PPF

  • Confirm the exact model code and stated finish on the quotation.
  • Request the current product data sheet and warranty terms for the intended market.
  • Ask the installer to review surface condition, panel coverage and installation scope.

Compare clear PPF options · Find an installer · Contact NEOPPF

MARINE PPF PLANNING

Marine Paint Protection Film

Use this page to compare the current product record, then confirm suitability for the actual watercraft surface and use conditions.

MARINE SURFACE FILM

Plan the film around the actual marine surface

Review the current model record, intended substrate, coverage area, operating environment and installation plan before specification.

CURRENT MODEL DATA
PROFESSIONAL INSTALLATION
Plan the film around the actual marine surface

What to confirm before specifying marine PPF

Build the decision around the exact film record, intended marine surface, operating environment and installer plan.

Exact model

Exact model

Match the product name, dimensions and current data sheet to the written quote.

Surface review

Surface review

Identify the substrate, coating history, condition and intended coverage before specification.

Operating environment

Operating environment

Document exposure, use and maintenance conditions for the actual watercraft.

Installer plan

Installer plan

Confirm preparation, patterning, edges, handover and inspection with the installer.

PRODUCT

CONSTRUCTION

HANDLING LAYER

A temporary handling layer used during transport or installation. Confirm the removal sequence in the current model instructions.

TOP COAT LAYER

The outer surface layer. Review the current data sheet for finish, care information and applicable test methods.

PCU FILM LAYER

The primary PCU film layer. Use the current model document for material and dimensional values.

ADHESIVE LAYER

The bonding layer. Follow the current model guidance and assess the actual paint or substrate before installation or removal.

PCU FILM LAYER OVERVIEW
PCU FILM LAYER OVERVIEW

Technical Data

Specifications

Use these page values as a comparison reference and confirm them against the current product data sheet for the exact model before specification.

Specifications Model-specific reference
01

Material Construction

Material Type
PCU （Polycarbonate-based Polyurethane）
Overall Thickness
12 mil
PCU Thickness
9.5 mil
Gloss (60°)
> 90 GU (GB8807)
Haze
≤1.5%
Yellowing Resistance (ΔE)
≤1.0 (3000h QUV)
Elongation at Break
300% (ASTM D412)
Tensile Strength
30 MPA (ASTM D412)
02

Application

Adhesive Type
Confirm the current adhesive and installation guidance for this exact model.
Application
Wet Apply Only
Usage
Gelcoat / Awlgrip / Alexseal

You may also like

Product Questions to Confirm Before Ordering

Choosing this product

Confirm the exact model, finish, available roll size, current technical data sheet and intended coverage. Then ask the installer to assess the actual vehicle or surface before the material is specified.

Compare the same fields on current documents: material family, finish, dimensions, test method and conditions, written warranty scope, installation requirements and sample appearance. A product name alone is not a complete comparison.

Appearance, care and service life

Appearance can change with the underlying surface, lighting, viewing angle, panel shape and installation quality. Review a physical sample on the intended surface before making an appearance decision.

Service life depends on the exact model, exposure, installation, use and care. Confirm the current written warranty for this model and market; warranty duration and expected service life are not the same thing.

Follow the current care instructions supplied for the exact model and the installer’s written handover. Ask when the surface may be washed, which products are compatible and how edges should be inspected.

Have a qualified installer inspect the film, original paint, repainted areas and panel history before removal. The appropriate method and outcome depend on the actual substrate and its condition.

Removal conditions and substrate history can affect residue and cleanup. Use the current removal guidance for the exact model and have the installer document any pre-existing paint or repair concerns.

Installation planning

Professional installation is recommended because surface preparation, patterning, film handling, edge work and final inspection are vehicle- and product-specific.

Use the current installation instructions for the exact model. Do not transfer a wet- or dry-installation method from another film without written confirmation.

Record the exact film, surface condition, panels or areas included, pattern method, edge strategy, installation environment, care handover and unresolved questions before work begins.

Repositioning behavior is product- and process-specific. Confirm it in the current installation guide and let the installer determine the method for the actual panel or surface.

Use the timing in the current installation instructions and the installer’s handover. Ask for a documented final inspection and any recommended follow-up check.

Confirm the current model-specific requirements for surface preparation, environment and handling. The correct conditions should come from the approved installation document, not a generic temperature range.

Confirm that the pattern data, software, film width and intended coverage match the actual vehicle and current roll before cutting.

The paint manufacturer’s cure requirements and the actual repair condition must be checked first. Ask the installer and repairer to confirm suitability in writing before installation.

Ordering and delivery

Provide the destination and intended product, then request current written confirmation of availability, packaging, freight method, charges, customs responsibilities and delivery estimate. These terms can vary by order and market.
